Specifications:

General

• Phase: Single Phase
• Form Factor: Tower
• UPS Topology: Line-interactive
• Energy Saving Technology: GreenPower UPS™ Bypass Technology

Input

• Generator Compatibility: Yes
• Nominal Input Voltage ( Vac ): 230 ± 10%
• Input Voltage Range ( Vac ): 167 ~ 295
• Input Frequency ( Hz ): 50 ± 5 60 ± 5
• Rated Input Current ( A ): 4.35
• Input Connector Type: IEC C14 　

Outout

• Capacity (VA): 1000
• Capacity (Watts): 550
• On Battery Waveform: Simulated Sine Wave
• On Battery Voltage(s) ( Vac ): 230 ± 10%
• On Battery Frequency ( Hz ): 50 ± 1% 60 ± 1%
• Automatic Voltage Regulation (AVR): Single Boost, Single Buck
• Overload Protection: Circuit Breaker
• Outlet(s) - Total: 6
• Outlet Type: IEC C13 x 6 　
• Outlet(s) - Battery & Surge Protected: 6
• Typical Transfer Time ( ms ): 4

Battery

• Runtime at Half Load ( min ): 9
• Runtime at Full Load ( min ): 1
• Typical Recharge Time ( Hours ): 8
• Start On Battery: Yes
• User-replaceable: Yes - Qualified Personnel Only
• Battery Type: Sealed Lead-acid

Surge Protection & Filtering

• Surge Suppression ( Joules ): 450
• EMI/RFI Filtration: Yes
• Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out

Management & Communications

• LCD Panel: Yes
• LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information
• LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning
• LED Indicators: Power On
• HID Compliant USB Port(s): 1
• Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
• Management Cable ( pcs ): Power Cord x1, USB Cable x1
• Ethernet Data Transmission Speed: Up to 1Gb
• Power Management Software: PowerPanel®Personal (Recommended)

Physical

• Enclosure Construction: Plastic
• Color: Black

Physical Size - Ups Module

• Dimensions (WxHxD) (mm.): 100 x 227 x 260
• Weight (kg.): 6.23

Environmental

• Operating Temperature (°C): 0 ~ 40
• Operating Relative Humidity (Non-condensing) ( % ): 0 ~ 90
• Operating Elevation ( meters ): 0-3,000 meters
• Storage Temperature (°C): -20 ~ 50
• Storage Relative Humidity (Non-condensing) ( % ): 0 ~ 90
• Storage Elevation ( meters ): 0-3,000 meters
• Online Thermal Dissipation ( BTU/hr ): 23.9
• Audible Noise at 1.0M from Surface of Unit ( dBA ): 40

Certifications

• Certifications: CE, EAC
• RoHS: Yes
